Provides all possible reference lines required in leveling, aligning, plumbing, and squaring applications for maximum versatility
Fast self-leveling time; stability is achieved in 3 seconds for increased productivity
Self-leveling is correctable up to 4° of slope allowing operation on uneven surfaces
Bright 635 nm class II laser for best-in-class visibility in moderate ambient light environment
Laser line fan length spans well past 90° point position to provide 180° horizontal line and 120° vertical line for full reference line coverage in demanding applications
Integrated pendulum lock enables slope incline applications for increased versatility
Pulse mode allows operation with laser receiver with detection achieved up to 200’
Pulse mode conserves and extends battery life for increased operation time in low light environments
Delivers up to 35 hours of continuous run time operation
Five dedicated mode functions conserve power by allowing battery power usage only when needed to operate the necessary functions
Recessed laser windows are highly protected from fracture damage in slot positions for increased durability
Full oversized rubber over-mold for increased protection
Pendulum lock offers added protection of laser diode during transport and storage
Dust and water resistance with IP 54 rating for increased durability
Simplified two button user interface for ease of operation
Integrated bracket allows for attachment to a tripod with a 1/4” & 5/8” thread or to metal and wood objects
Specifications:
Battery: 4xAA
Point Beam Direction: 4 point up, down, left right
